Experience phenomenal audio performance and seamless operation with the AKG C114 Large Diaphragm Multi-Pattern Condenser Microphone. Drawing from a rich musical heritage and crafted for today’s creative innovators, it’s tailored for musicians, podcasters, YouTubers, and streamers.
The C114 features an edge-terminated capsule—echoing the celebrated design of world-renowned AKG C12 and C414 microphones. Integrated cardioid, omnidirectional, and figure-of-eight polar patterns offer the utmost in capture versatility. An advanced transformerless FET circuit delivers pristine clarity.
Sustainability is integral to its design. The C114 microphone body is made from 100% recycled PIR metals and alloys, and every component—from packaging to accessories—is designed to minimize environmental impact.
Enhance your creative projects with the AKG C114 Large Diaphragm Multi-Pattern Condenser Microphone, where classic inspiration meets modern innovation.
Key Features
Edge-Terminated Large Diaphragm Capsule
An AKG innovation from the classic C12, this edge-terminated, gold-sputtered capsule offers a smooth top end and balanced frequency response.
High Headroom, Minimum Distortion
Capable of handling sound pressure levels up to 145dB without introducing perceptible distortion, the microphone delivers excellent results across a wide range of applications.
Ultra-Wide Dynamic Range
With an extremely low noise floor and high Max SPL, the C114 can clearly capture nearly any source. From loud electric guitars to the faintest whispers, you’ll get clean, detailed recordings every time.
Environmentally Friendly Design
Thoughtfully engineered for sustainability, the C114 features a body made from 100% recycled PIR metal. Accessories and packaging are designed with minimal environmental impact and are fully recyclable.
Specifications
- Capsule Type: 26mm Dual Diaphragm, true condenser pressure gradient
- Polar Pattern: Cardioid, Omnidirectional, Figure-of-Eight
- Sensitivity: (cardioid) 13.5mV/Pa (-37.4 dBV)
- Frequency Response: 20Hz – 20kHz
- Electrical Impedance: ≤200 ohms
- Recommended Load Impedance: ≥1000 ohms
- Self-Noise Level: 12dB(A) SPL
- Signal-to-Noise Ratio: 82dB re 1 Pa
- Max SPL (0.5% THD): 145dB SPL
- Temperature Range: -5 to 50°C (23 to 122°F)
- Phantom Power: 48V ±4V (IEC 61938)
- Current Consumption: ≤5 mA
- Connector: 3-pin XLR (pin 2 hot)
- Dimensions (L×W×H): 6.22 × 1.85 × 1.38 in (158 × 47 × 35mm)
- Weight: 0.92 lbs (415g)
